Pulse Electronics CorporationJX30 0005NLSteckverbinder, Telefon und Telekommunikation
Conn RJ-45 F 4 POS 2.54mm Solder RA SMD 8 Terminal 1 Port
| Compliant with Exemption | |
| EAR99 | |
| Active | |
| 8536.69.40.40 | |
| Automotive | No |
| PPAP | No |
| RJ-45 | |
| F | |
| 8 | |
| 4 | |
| 12 | |
| Solder | |
| 2.54 | |
| Right Angle | |
| Green/Yellow | |
| 750 | |
| Yes | |
| 0 | |
| 70 | |
| Single | |
| 16.1 | |
| 25.4 | |
| 13.61 | |
| Surface Mount |
You will never drop a call again with this rj-45 JX30-0005NL telephone and telecom connector from Pulse. This F connector's 4 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. It has a female type gender. This connector has a single port. It has a right angle body orientation. It uses the solder termination method. This product is 16.1 mm long, 13.61 mm tall and 25.4 mm deep. This part has an operating temperature of 0 to 70 °C. JX30-0005NL is housed in thermoplastic.
