LTC3732CG Demo Board, 3-Phase, CPU Core Power Supply, 5V to 20V Input, VRM9.0 @ 65A Max
Referenzdesign unter Verwendung des Teils LTC3732CG von Analog Devices
Bilder
1 / 2
Zugehörige Dokumente
Für Endprodukte
- Desktop PC
- Laptop
- Notebook
- Power Supplies
Beschreibung
- Demonstration circuit DC440A is a VRM9.x power supply for powering Intel Pentium-4 CPUs. The input voltage is 7V to 20V, the output voltage is programmed by the 5-bit VID inputs. The maximum output current is 65A
Haupteigenschaften
-
Conversion TypeDC to DC
-
Input Voltage7 to 28 V
-
Output Current65 A
-
TopologyBuck
