NB6L14MMNGEVB, CML Clock/Data Fan-out Buffer Evaluation Board
Referenzdesign unter Verwendung des Teils NB6L14MMNG von onsemi
Bilder
1 / 2
Für Endprodukte
- Backplane Distributed Power
- Clock Management and Distribution
Beschreibung
- NB6L14MMNGEVB, CML Clock/Data Fan-out Buffer Evaluation Board. The NB6L14M is a 3.0GHz differential 1:4 CML clock or data fan-out buffer. The differential inputs incorporate internal 50-ohm termination resistors that are accessed through the VT pin. This feature allows the NB6L14M to accept various logic standards, such as CML, LVCMOS, LVTTL, CML, or LVDS logic levels. The 16mA differential CML outputs provide matching internal 50-ohm terminations and produce 400mV output swings when externally terminated with a 50-ohm resistor to VCC. The VREFAC reference output can be used to re-bias capacitor-coupled differential or single-ended input signals. The 1:4 fan-out design was optimized for low output skew applications
Haupteigenschaften
-
Operating Frequency3000 MHz
Empfohlene Bauteile (1)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
NB6L14MMNG | onsemi | Clock Buffers and Drivers | Clock Fanout Buffer 4-OUT 1-IN 1:4 16-Pin QFN EP Tube | In den Warenkorb | |
