PRUCAPE, is a BeagleBone Black add-on board that allows users get to know TI's powerful Programmable Real-Time Unit (PRU) core and basic functionality
Referenzdesign unter Verwendung des Teils MAX3232ECD von Texas Instruments
Bilder
1 / 5
Zugehörige Dokumente
Für Endprodukte
- Electrocardiograph Battery Powered
- Laptop
- Notebook
- Personal Digital Assistant
Beschreibung
- PRUCAPE, PRU Cape is a BeagleBone Black add-on board that allows users get to know powerful Programmable Real-Time Unit (PRU) core and basic functionality. The PRU is a low-latency microcontroller subsystem integrated in the Sitara AM335x and AM437x family of devices. The PRU core is optimized for deterministic, real-time processing, direct access to I/Os and ultra-low-latency requirements. It includes LEDs and Push-Buttons for GPIO, audio and a temp sensor. Together the BeagleBone Black and PRUCAPE are an ideal EVM solution to begin PRU development on the Sitara platform
Haupteigenschaften
-
Interface StandardsRS-232
-
FunctionsLine Transmitter/Receiver
Empfohlene Bauteile (6)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
DAC082S085CIMM/NOPB | Texas Instruments | Digital to Analog Converters - DACs | DAC 2-CH Resistor-String 8-bit 10-Pin VSSOP T/R | In den Warenkorb | |
|
LM4808MX/NOPB | Texas Instruments | Audio Amplifiers | Audio Amp Headphone 2-CH Stereo 0.15W Class-AB 8-Pin SOIC T/R | In den Warenkorb | |
|
MAX31820MCR+T | Analog Devices | Temperature and Humidity Sensors | Temp Sensor Digital Serial (1-Wire) 3-Pin TO-92 T/R | In den Warenkorb | |
|
|
MAX31820MCR+ | Analog Devices | Temperature and Humidity Sensors | Temp Sensor Digital Serial (1-Wire) 3-Pin TO-92 Bag | In den Warenkorb | |
|
|
DAC082S085CIMM/NOPB | Texas Instruments | Digital to Analog Converters - DACs | DAC 2-CH Resistor-String 8-bit 10-Pin VSSOP T/R | In den Warenkorb | |
|
|
LM4808MX/NOPB | Texas Instruments | Audio Amplifiers | Audio Amp Headphone 2-CH Stereo 0.15W Class-AB 8-Pin SOIC T/R | In den Warenkorb | |
