REFD4376, Reference Design for a High-Input-Voltage, High-Output-Current Buck Controller Using the MAX15046
Referenzdesign unter Verwendung des Teils MAX15046 von Analog Devices
Bilder
1 / 2
Zugehörige Dokumente
Für Endprodukte
- High-Voltage Applications
- Low-Voltage Applications
Beschreibung
- REFD4376, Reference design presents a circuit for using the MAX15046 step-down power-supply controller for high-input-voltage, low-output-voltage applications that require high output current
Haupteigenschaften
-
Conversion TypeDC to DC
-
Input Voltage18 to 36 V
-
Output Voltage1.2 V
-
Output Current13.4 A
-
Efficiency82 %
-
TopologyBuck
