TIDA-00352, SDI Video Aggregation Reference Design
Referenzdesign unter Verwendung des Teils TLK10022CTR von Texas Instruments
Bilder
1 / 28
Zugehörige Dokumente
- TIDA-00352 Test Results
- TIDA-00352 Schematic (Daughter Card)
- TIDA-00352 CAD Files (Daughter Card)
- TIDA-00352 Schematic (Motherboard)
- TIDA-00352 CAD Files (Motherboard)
- TIDA-00352 PCB (Motherboard)
- TLK10022 EVM Quick Start Guide
- TIDA-00352 BOM (Daughter Card)
- TIDA-00352 PCB (Daughter Card)
- TIDA-00352 BOM (Motherboard)
Für Endprodukte
- Digital Signage
Beschreibung
- TIDA-00352, SDI Video Aggregation Reference Design. This verified reference design is a complete four channel SDI aggregation and de-aggregation solution. One TLK10022 is used to aggregate four synchronous HD-SDI sources together into one 5.94 Gbps serial link. The serial data is transferred via copper or optical fiber where a second TLK10022 is used to de-aggregate and seamlessly redisplay the original video content
Haupteigenschaften
-
Video Interface TypeHD-SDI
Empfohlene Bauteile (13)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
TPS3125J18DBVR | Texas Instruments | Supervisory Circuits | Processor Supervisor 1.62V 1 Active High/Active Low/Push-Pull 5-Pin SOT-23 T/R | In den Warenkorb | |
|
TPS74401RGWT | Texas Instruments | Linear Regulators | LDO Regulator Pos 0.8V to 3.6V 3A 20-Pin VQFN EP T/R | In den Warenkorb | |
|
CDCM6208V1RGZR | Texas Instruments | Clock Generators and Synthesizers | Clock Generator 0.008MHz to 250MHz-IN 800MHz-OUT 48-Pin VQFN EP T/R | In den Warenkorb | |
|
TXB0108PWR | Texas Instruments | Level Translators | Voltage Level Translator 8-CH Bidirectional 20-Pin TSSOP T/R | In den Warenkorb | |
|
|
TXS0108EPWR | Texas Instruments | Level Translators | Voltage Level Translator 8-CH Bidirectional 20-Pin TSSOP T/R | In den Warenkorb | |
|
|
CDCM6208V1RGZT | Texas Instruments | Clock Generators and Synthesizers | Clock Generator 0.008MHz to 250MHz-IN 800MHz-OUT 48-Pin VQFN EP T/R | In den Warenkorb | |
|
|
TLV70225DBVT | Texas Instruments | Linear Regulators | LDO Regulator Pos 2.5V 0.3A 5-Pin SOT-23 T/R | In den Warenkorb | |
|
CDCLVP1204RGTT | Texas Instruments | Clock Buffers and Drivers | Clock Fanout Buffer 4-OUT 2-IN 1:4 16-Pin VQFN EP T/R | In den Warenkorb | |
|
|
SN74LVC1G08DBVR | Texas Instruments | Logic Gates | AND Gate 1-Element 2-IN CMOS 5-Pin SOT-23 T/R | In den Warenkorb | |
|
|
TLV70233DBVT | Texas Instruments | Linear Regulators | LDO Regulator Pos 3.3V 0.3A 5-Pin SOT-23 T/R | In den Warenkorb | |
|
TCA6424ARGJR | Texas Instruments | GPIO Expanders | I2C Interface 100kHz/400kHz 5.5V 32-Pin UQFN EP T/R | In den Warenkorb | |
|
SN74AVCH1T45DCKR | Texas Instruments | Level Translators | Voltage Level Translator 1-CH Bidirectional 6-Pin SC-70 T/R | In den Warenkorb | |
