TIDEP0013, Embedded USB 2.0 Reference Design
Referenzdesign unter Verwendung des Teils XAM437XAZDN von Texas Instruments
Bilder
1 / 5
Zugehörige Dokumente
Für Endprodukte
- Barcode Scanner
- Industrial
- Navigation System
- Patient Monitoring
- Portable
- Test Equipment
Beschreibung
- TIDEP0013, Embedded USB 2.0 Reference Design. The USB 2.0 reference design guidelines are extremely important for designers who want to ensure that their design will pass USB2.0 electrical compliance testing. The guidelines are applicable to AM335x and AM437x but also generic to other processors. The approach taken for these guidelines is highly practical, without complex formulas or theory
Haupteigenschaften
-
Embedded System TypeSoC
-
Family NameSitara AM437x
-
Core ProcessorARM Cortex-A9
Empfohlene Bauteile (3)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
TPS63010YFFT | Texas Instruments | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 2V to 5.5V Non-Inv/Inv/Step Up/Step Down Single-Out 1.2V to 5.5V 1.2A 20-Pin DSBGA T/R | In den Warenkorb | |
|
|
TPS63010YFFR | Texas Instruments | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 2V to 5.5V Non-Inv/Inv/Step Up/Step Down Single-Out 1.2V to 5.5V 1.2A 20-Pin DSBGA T/R | In den Warenkorb | |
|
TPS2051BD | Texas Instruments | USB Power Switches | Power Switch Hi Side 3-OUT 0A 0.075mOhm 8-Pin SOIC Tube | In den Warenkorb | |
