TIDM-SERVODRIVE, Industrial Servo Drive and AC Inverter Drive Reference Design
Referenzdesign unter Verwendung des Teils TMS320F28377DZWT von Texas Instruments
Bilder
1 / 22
Für Endprodukte
- CNC Machine
- Elevator
- Industrial Drives
- Robotics
- Servo Drives
Beschreibung
- TIDM-SERVODRIVE, Industrial Servo Drive and AC Inverter Drive Reference Design. The Design DRIVE Development Kit is a reference design for a complete industrial drive directly connecting to a three phase ACI or PMSM motor. Many drive topologies can be created from the combined control, power and communications technologies included on this single platform. Includes multiple position sensor interfaces, diverse current sensing techniques, hot-side partitioning options and expansion for safety and industrial Ethernet
