TIDM-SMARTMETERMSP430, Modular Smart Meter Reference Design for Evaluating Communications Technologies
Referenzdesign unter Verwendung des Teils MSP430F47197 von Texas Instruments
Bilder
1 / 6
Zugehörige Dokumente
- Modular Smart Meter Design for Evaluating Communications Technologies Schematic
- Modular Smart Meter Design for Evaluating Comms. Technologies Design Files
- Modular Smart Meter Design for Evaluating Communications Technologies BOM
- Modular Smart Meter Design for Evaluating Comms. Technologies Gerber
- Modular Smart Meter Design for Evaluating Comms. Technologies Test Results
Für Endprodukte
- E-Power Meter
- Power Line Communication
Beschreibung
- TIDM-SMARTMETERMSP430, Smart Meter Board (SMB) 2.5 is a modular development platform incorporating key Smart Grid. The SMB makes it simpler for developers to compare different communications solutions to determine which options are the best fit for their application by replacing different add-in cards to evaluate various Smart Grid communications options including ZigBee, sub-1GHz wireless, and power line communications. The SMB includes the MSP430FF47197 SoC to perform three-phase energy measurement and act as the system host processor
Haupteigenschaften
-
Embedded System TypeMCU
-
Family NameMSP430
