TIDM-THREEPHASE-BLDC-LC-INST, 3-Phase Brushless/PMSM Low Current Motor Control Solution with InstaSPIN Software
Referenzdesign unter Verwendung des Teils DRV8312DDW von Texas Instruments
Bilder
1 / 9
Zugehörige Dokumente
Für Endprodukte
- CPAP Machine
- Drill/Screw Driver
- E-Bike
- Medical and Healthcare
- Power Tool
- Pumps
- Robotics
- Scooter
Beschreibung
- TIDM-THREEPHASE-BLDC-LC-INST, Reference Design demonstrates a motor control solution for spinning three-phase brushless DC (BLDC) and brushless AC (BLAC) - often referred to as permanent magnet synchronous (PMSM) - motors featuring the C2000 Piccolo microcontroller and the DRV8312 3-phase motor driver. The reference design features a high-performance, power-efficient, cost-effective sensorless field-oriented control (FOC) and sensor/sensorless trapezoidal commutation platform that speeds development for quicker time to market. This reference design is based on the DRV8312 evaluation kit
Haupteigenschaften
-
Motor TypeDC Motor
Empfohlene Bauteile (36)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
ISO1050DUBR | Texas Instruments | Controller Area Network - CAN Transceivers | CAN 1Mbps 3.3V/5V 8-Pin SOP T/R | In den Warenkorb | |
|
TPS54160DGQR | Texas Instruments | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 3.5V to 60V Synchronous Step Down Single-Out 0.8V to 58V 1.5A 10-Pin HVSSOP EP T/R | In den Warenkorb | |
|
UA78M05CDCYRG3 | Texas Instruments | Linear Regulators | Standard Regulator Pos 5V 0.5A 4-Pin(3+Tab) SOT-223 T/R | In den Warenkorb | |
|
REF3025AIDBZT | Texas Instruments | Voltage References | V-Ref Precision 2.5V 25mA 3-Pin SOT-23 T/R | In den Warenkorb | |
|
|
TL1963A-33DCYR | Texas Instruments | Linear Regulators | LDO Regulator Pos 3.3V 1.5A 4-Pin(3+Tab) SOT-223 T/R | In den Warenkorb | |
|
SN74LVC2G07DCKR-P | Texas Instruments | Buffers and Line Drivers | Buffer/Driver 2-CH Non-Inverting Open Drain CMOS 6-Pin SC-70 | In den Warenkorb | |
|
SN74LVC2G07DBVR | Texas Instruments | Buffers and Line Drivers | Buffer/Driver 2-CH Non-Inverting Open Drain CMOS 6-Pin SOT-23 T/R | In den Warenkorb | |
|
CAS-D20TA | NIDEC COMPONENTS CORPORATION | Switch Slide | Switch Slide ON ON DPDT Recessed Slide 0.1A 24VDC J-Lead SMD T/R | In den Warenkorb | |
|
OPA365AIDBVR | Texas Instruments | Operational Amplifiers - Op Amps | Op Amp Single High Speed Amplifier R-R I/O ±2.75V/5.5V 5-Pin SOT-23 T/R | In den Warenkorb | |
|
|
TPS73633MDBVREPG4 | Texas Instruments | Linear Regulators | LDO Regulator Pos 3.3V 0.4A 5-Pin SOT-23 T/R | In den Warenkorb | |
|
|
SN74LVC2G07DCKR | Texas Instruments | Buffers and Line Drivers | Buffer/Driver 2-CH Non-Inverting Open Drain CMOS 6-Pin SC-70 T/R | In den Warenkorb | |
|
TXB0106PWR | Texas Instruments | Level Translators | Voltage Level Translator 6-CH Bidirectional 16-Pin TSSOP T/R | In den Warenkorb | |
