BQ24721EVM, evaluation module is a complete charger module for evaluating a multi-cell synchronous notebook charge and path selection solution using bq24721 device
Referenzdesign unter Verwendung des Teils bq24721RHB von Texas Instruments
Bilder
1 / 2
Für Endprodukte
- Laptop
- Netbook
- Notebook
Beschreibung
- BQ24721EVM, evaluation module is a complete charger module for evaluating a multi-cell synchronous notebook charge and path selection solution using bq24721 device. It is designed to deliver up to 9A of charge current to Li-Ion or Li-Pol applications
Haupteigenschaften
-
Battery TypeLithium-Ion|Lithium-Polymer
-
Input Voltage13 to 24 V
-
Output Voltage20 V
Empfohlene Bauteile (9)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
BQ24726RGRR | Texas Instruments | Battery Management ICs | Switching Battery Charger Controller Li-Ion 1.024V to 19.2V 20-Pin VQFN EP T/R | In den Warenkorb | |
|
BQ24721CRHBR | Texas Instruments | Battery Management ICs | Switching Battery Charger Controller Li-Ion/Li-Pol/NiCd/NiMH 8000mA 9V to 19.2V 32-Pin VQFN EP T/R | In den Warenkorb | |
|
|
BQ24725ARGRR | Texas Instruments | Battery Management ICs | Switching Battery Charger Controller Li-Ion/Li-Pol 8000mA 1.024V to 19.2V 20-Pin VQFN EP T/R | In den Warenkorb | |
|
|
BQ24725RGRT | Texas Instruments | Battery Management ICs | Switching Battery Charger Controller Li-Ion/Li-Pol 8000mA 1.024V to 19.2V 20-Pin VQFN EP T/R | In den Warenkorb | |
|
|
BQ24725ARGRT | Texas Instruments | Battery Management ICs | Switching Battery Charger Controller Li-Ion/Li-Pol 8000mA 1.024V to 19.2V 20-Pin VQFN EP T/R | In den Warenkorb | |
|
|
BQ24721CRHBT | Texas Instruments | Battery Management ICs | Switching Battery Charger Controller Li-Ion/Li-Pol/NiCd/NiMH 8000mA 9V to 19.2V 32-Pin VQFN EP T/R | In den Warenkorb | |
|
|
BQ24721CRHBTG4 | Texas Instruments | Battery Management ICs | Switching Battery Charger Controller Li-Ion/Li-Pol/NiCd/NiMH 8000mA 9V to 19.2V 32-Pin VQFN EP T/R | In den Warenkorb | |
|
|
BQ24725RGRR | Texas Instruments | Battery Management ICs | Switching Battery Charger Controller Li-Ion/Li-Pol 8000mA 1.024V to 19.2V 20-Pin VQFN EP T/R | In den Warenkorb | |
|
|
BQ24726RGRT | Texas Instruments | Battery Management ICs | Switching Battery Charger Controller Li-Ion 1.024V to 19.2V 20-Pin VQFN EP T/R | In den Warenkorb | |
