SMV512K32-CVAL, Breakout Evaluation Board for SMV512K32 16-Mbit Asynchronous SRAM Memory
Referenzdesign unter Verwendung des Teils SMV512K32HFG von Texas Instruments
Bilder
1 / 3
Für Endprodukte
- SRAM Memory
Beschreibung
- SMV512K32-CVAL, SMV512K32-SP Breakout Evaluation Board. The SMV512K32-CVAL is a circuit board which allows the designer to populate the SMV512K32 16-Mbit Asynchronous SRAM memory into the ENPLAS OTQ-132-0.635-01 socket. This breakout board can be used in tandem with a pattern generation and capture hardware to demonstrate the memory function features of the 16-Mbit asynchronous SRAM memory
Haupteigenschaften
-
Data Bus Width16M Bit
Empfohlene Bauteile (1)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
SMV512K32HFG | Texas Instruments | SRAM Chip | SRAM Chip Async Single 3.3V 16M-bit 512K x 32 20ns 76-Pin CFPAK Tray | In den Warenkorb | |
